Improve laboratory workflow with the FS3700 by running multiple flow methods (including SFA, FIA, iSFA, and SFIA) on different channels simultaneously. Ideal for the analysis of ammonia, chloride, cyanide, fluoride, nitrate, phenol, phosphorous, silica, TKN, and more! FS3700 Features: Intuitive software - FlowView™ Software streamlines operation Fast results - Performs 30-90 analyses per hour, per channel Versatile – Uses interchangeable, pre-assembled chemistry cartridges Flexible – Tailors methodology with two plug-in detector modules Accurate – Expanded Range™ photometric detector and autoscaling software eliminate off-scale samples Analysis Module 1 or 2 chemical analysis channels per chassis Analysis Module Dimensions 31 in. W x 17.5 in. D x 10.5 in. H 78.74 cm W x 44.45 cm D x 26.67 cm H FS 3700 Dimensions with 90-position Autosampler Approximately 44 in. (112 cm) W FS 3700 Dimensions with 360-position Autosampler Approximately 51.5 in. (131 cm) W Injection Valve 8 or 10-port switching valve with chemically-inert wetted surfaces Photometric Detector 420-880 nm, with PEEK path lengths of 5-, 10- or 20-mm Amperometric Detector Silver working electrode silver/silver chloride reference stainless steel counter electrode In-line Heater Included as needed, mounted underneath chemistry cartridge user programmable in 1 ̊C increments UV-digestion Module Included as needed, mounted underneath chemistry cartridge Peristaltic Pump 24-channel, fits on top of analysis module Autosampler 90-position, X-Y-Z (90 samples + 9 standards) 360-position, X-Y-Z (360 samples + 10 standards) Tubing FEP Teflon® and EVA ethylene-vinyl acetate copolymer Manifolds / Fittings Polysulfone Analysis Methods / Documentation Validated chemistries for specific analytes / sample matrices with performance data Operating Software FlowView Operating System Windows® 7, Windows® 8, 8.1 and 10 Data Collection 6 channels per instance of software Multiple instances of software can be run on a single computer PC to FS 3700 Communications USB Power Supply 24VDC universal switching power supply for operation with 90-250VAC 50/60Hz source Power Requirements 110VAC/60 Hz or 230VAC/50 Hz Weight (Analysis Module) 19.5 kg (43 lbs.), typical for analysis module and pump, two injection valves, chemistry cartridges, detector modules Certifications CE Safety EN 61010-1 EMC Immunity & Emissions EN 61326-1:2006 Methods:  Ammonia Nitrogen by USEPA 350.1 Ammonia/TKN by SFA and Gas Diffusion ASTM D7237 Available Cyanide by ASTM D6888 Chloride by Standard Methods Free Cyanide by ISO 14403 Hexavalent Chromium Low-Level Phosphorus (All Forms) by USEPA 365.1 MBAS by ISO 16265 Nitrate Nitrite in Water using FIA & SFA Nitrate and Nitrite in Milk OIA-1677 Available Cyanide by Ligand Exchange Post-Distillation Cyanide by USEPA 335.4 Post-distillation Phenol by USEPA-420.4 Sulfate by USEPA 375.2

Caracteristici Gama larga de accesorii – Echipamentul poate fi conectat la accesorii ca: modulul de control al temperaturii, suport pentru probele solide si lichide, suport multiplu pentru cuve, modul pentru masurarea reflexie speculare, modul pentru masurarea reflexiei dufuze, fibra optica etc. Un compartiment mare pentru probe – Compartimentul detine incorporat un controler pentru accesorii. Domeniul fotometric mare – Domeniul fotometric este de pana la 6,00 Abs, aplicabil pentru analiza probelor cu o turbiditate inalta si a probelor solide. Softul de operare WinUV – Softul are un design modular si o interfata simpla de utilizare, fiind aplicabil cu un domeniu larg de aplicatii. Latimea variabila a benzii spectrale – Latimea benzii spectrale este incadrata in intervalul 0,2 – 4 nm (cu pasul de modificare – 0,1 nm) si va da posibilitatea de a obtine un control optim asupra rezolutiei spectrale. Sistem optic protejat – Sistemul optic este etans, acoperit cu cuart, fapt ce previne expunerea la corozie si inlesneste procesul de curatare. Controlul automatizat al fazei undei, la miscarea lungimii de unda, previne deplasarea si suprimarea varfului din spectru, ce poate aparea la o viteza de scanare mare.

Sistemele cromatografice Agilent 1290 Infinity II reprezinta noua generatie de echipamente UHPLC ce va permit obtinerea maximului de eficienta analitica, instrumentala si operationala. Maxima eficienta analitica: • Componentele cu design special utilizate pe traseul de introducere al probei asigura o dispersie minima si prin urmare o rezolutie cromatografica net superioara altor sisteme UHPLC. • Faciliteaza implementare rapida a metodelor 2D-LC simplificand analiza probelor complexe. • Prin capabilitatile multiple de curatare a injectorului permite reducerea efectului de carry-over la mai putin de 10 ppm chiar si pentru compusi dificil de indepartat (ex. Clorhexidina). • Prin utilizarea noilor detectori 1290 Infinity II HDR-DAD sau 1290 Infinity II ELSD beneficiati de o capacitate sporita de detectie tradusa atat prin scaderea limitelor de detectie dar si prin cresterea intervalului dinamic de liniaritate. Maxima eficienta instrumentala: • Utilizarea injectorului dublu permite injectarea ultrarapida a probelor la mai putin de 5s intre doua injectii succesive. • Designul innovator al autosamplerului permite introducerea si pastrarea in conditiile de temperatura impuse de metoda a pana la 6144 de probe, in spatiul ocupat doar de autosamplerul insusi. • Fittinguri-le revolutionare A-line utilizate pentru conectarea coloanelor au fost gandite si realizate astfel incat sa asigure maxima usurinta in montaj si zero volum mort. • Beneficiati de flexibilitate crescuta pentru aplicatiile ce pot fi dezvoltate pe astfel de sisteme datorita intervalului larg de presiuni disponibile, caracteristicilor speciale ale injectorului precum si utilizarii aplicatiei software ISET ce va permite reproducerea conditiilor de separare de pe oricare echipament HPLC sau UHPLC. Trasaturi: Maxima eficienta operationala in cadrul laboratorului: • Integrare ultrarapida in structura preexistenta de echipamente si metode cu ajutorul tehnologiei ISET • Poate fi controlat si prin intermediul sistemelor de date Waters Empower sau Dionex Chromeleon datorita sistemului Agilent ICF (Instrument Control Framework) • Asigura cele mai mici costuri aferente posesiei echipametului

The Agilent 240 AA system combines rugged and reliable hardware with easy-to-use software, making it ideal for low-throughput laboratories. Featuring true double-beam optics, D2 background correction, and the Mark 7 flame atomization system (standard), the 240 AA system is well suited to environmental, food, and agriculture applications. The Mark 7 spray chamber is simple to use, with twist-and-lock assembly and plastic components designed to handle the challenging samples encountered in materials and mining applications. The 240 AA can be fitted with a full range of AA accessories to further extend its capabilities. Features Designed for dusty, corrosive environments—completely sealed optics with quartz overcoated mirrors; optional air purge continually cleans the inside of the instrument to exclude corrosive vapors. Fast response background correction—the high intensity deuterium background corrector has a fast 2-ms response time ensuring accurate correction of transient background signals. Easy lamp maintenance—the lamp is immediately accessible for easy adjustment or replacement without needing to remove the instrument covers. Automation to fit the need and budget—Automatic wavelength and slit selection, four fixed-lamp positions for quick, reliable lamp changes, and a next lamp warm-up feature that saves analysis time. Expandable—analyze mercury and hydrides at trace ppb levels using the continuous flow vapor generation accessory (VGA 77). Add the ETC 60 for unattended, flameless atomization of hydride elements. Upgradable—The 240 AA can be easily upgraded at any time. Reduces ownership costs—Rapid troubleshooting and fault diagnosis keep your lab up and running faster. The Telediagnostics option connects to our worldwide network of on-line support personnel.
